FTTH Cable Production: Step-by-Step Manufacturing Process
Quick fact: in excess of seventy percent of new broadband deployments in the U.S. now rely on fiber networks that require high-precision manufacturing to hit performance targets.
Shanghai Weiye OFC Equipment manages full-cycle compact fiber unit manufacturing, from selecting brand fibers like Fujikura or Corning® SMF-28e to complete test reports that deliver 100% QA.
Our FTTH drop designs fit aerial, ducted, and direct burial installation, with LSZH, PVC, and polyethylene (PE) jacket options and arrangements from 1 to 4 cores. We supply single-mode OS1/OS2 and multimode OM2–OM4 grades plus ITU-T G.652D and G.657 variants, Pantone sheath colors, and custom logo printing.
Automation and precision equipment stabilize line speed and repeatability high. Typical lead times run four to five days for orders < 100 km and seven to ten days under 500 km, with an MOQ of 1 km and warranty covering free replacement for confirmed quality issues.
Read on to see how our materials, tests, and support combine to lower lifecycle cost and pair the right product with your network.
- Shanghai Weiye OFC Equipment delivers end-to-end manufacturing and lab testing for United States projects.
- Multiple jacket choices and fiber grades cover varied installation environments.
- Automated production lines ensure consistent quality and reliable optical performance.
- Fast lead times, low MOQ, and brand fiber options help plan procurement reliably.
- Complete reports and warranty back product reliability and compliance documentation needs.
FTTH Manufacturing Expertise by Shanghai Weiye OFC Equipment
When deadlines and performance are critical, Shanghai Weiye OFC Equipment delivers tailored drop solutions with complete test documentation.
As a specialized maker and supplier, Shanghai Weiye OFC Equipment combines purpose-built equipment with tight material control. We provide custom builds and services for single-family and MDU rollouts. Every order comes with 100% quality assurance and complete test reports.
Our lab runs high-temperature, salt-fog, and vibration testing to validate durability. Jacket options include LSZH, PVC, and PE. Designs offer bow-type flat and figure-8/self-supporting styles and support brand fibers such as Fujikura and Corning® SMF-28e.
- Documented line control and production checks for shipments with audit trails.
- Engineering support for specs, trials, and ramp to volume.
- Modern fixtures and calibration minimize variation so every cable matches operator specs.
FTTH Cable Production
At Shanghai Weiye OFC Equipment, manufacturing steps are matched to network specs, pairing brand fiber choices with rigorous test routines.
Optical fiber selection and brand options
We select fiber draw tower to minimum bend radius, attenuation, and deployment type. Options include OS1, OS2, OM2–OM4 and G.652D and G.657.A1/A2 per ITU-T. Brand fibers such as Fujikura® and Corning SMF-28e are available to satisfy sourcing standards.
Strength member integration
Strength members use dielectric FRP or galvanized steel wire. FRP is preferred where non-conductive runs are required. Steel wire provides tensile strength for longer aerial spans and bonding/grounding needs.
Jacket extrusion and process control
Jacket options include LSZH for indoor flame safety, PVC for flexibility and ease of handling, and PE for UV/moisture resistance outdoors. Tight process control of temperature and capstan ratios stabilizes line speed and dimensional tolerances.
| Member | FRP | Metallic Steel |
|---|---|---|
| Use case | Electrical isolation | Aerial spans, high tensile |
| Advantage | Light, non-corrosive | High strength |
| Installer note | Simple terminations | Bonding/grounding required |
Testing & Verification
Inline geometry and concentricity checks operate in-line. Final optical tests verify loss and return loss. Each order includes a full test report and lab results from high-temperature, salt-spray, and vibration tests to confirm handling for drop terminations and field use.
Typical lead times are 4–5 days for < 100 km and 7–10 days for < 500 km. Material lot records and first-article approvals provide traceability and compliance for U.S. projects.
FTTH drop cable types and structures we manufacture
Shanghai Weiye OFC Equipment provides a compact portfolio of drop designs that fit indoor risers and long aerial runs. Each option pairs tested materials with geometry tuned for field termination and stable optical performance.
The flat bow-type drop keeps a small footprint for risers and conduit. It reduces bend loss for easy routing in hallways and MDUs.
Self-Supporting Aerial Designs
Self-supporting FTTH drop designs include a support messenger to carry tensile loads. Choose dielectric FRP for electrical isolation or steel wire when bonding and higher tensile strength are required.
Core Layouts and Strength Members
We offer both dielectric and metallic strength member configurations to match safety and EMI rules. Central loose-tube and unitube flat types balance crush resistance and Fiber coloring machine for fast terminations.
Indoor vs Outdoor Jackets
Jacket choices include LSZH for flame-retardant, low-smoke indoor use and PE for outdoor UV and moisture resilience. Each series is validated for mechanical and optical quality before shipment.
| Type | Best use | Strength member | Jacket |
|---|---|---|---|
| Bow-type flat | Indoor risers and MDUs | Dielectric FRP | Low-smoke zero-halogen |
| Self-supporting | Aerial spans | FRP/Steel | Polyethylene |
| Center loose tube | Higher-count builds | FRP | LSZH or PE |
| Flat unitube | Low count, quick strip | FRP/Steel | LSZH/PE |
Equipment Ensuring Quality and Throughput
Automation with sensor feedback at Shanghai Weiye OFC Equipment reduce manual handling and boost throughput for patch cord prep.
Our production line integrates automated machines that cut/strip drop cords to raise throughput and cut labor variability.
The CLX-BPO2 automated stripper runs under PLC and photoelectric control. One cycle is ~1.5 s, giving real-world speeds near 20 terminal operations per minute.
Automated Cut/Strip for Drop Cords
The equipment strips LSZH/PVC jackets and trims FRP or steel strength members to precise stub lengths. Cylinder-driven actuators deliver fast, repeatable motion and minimize downtime.
PLC & Photoelectric for Precision
PLC logic and photoelectric sensors give exact positioning and feedback control. Inline checks update SPC charts so operators can correct trends before out-of-control conditions occur.
| Feature | Spec | Benefit |
|---|---|---|
| Machine | Auto-strip, ~1.5 s cycle | High throughput |
| Actuation | Cylinder-based | High speed and reliability |
| Materials | LSZH & PVC; FRP & steel | Clean, accurate preps |
| Process control | PLC + photoelectric + inline checks | Consistent quality, lower rework |
- Auto scrap ejection and ergonomic feeders keep the line clean.
- Process control plans document calibration and key parameters.
- Integrated assets and trained operators help meet FTTH volume goals without sacrificing accuracy.
CLX-BPO2 Capabilities on Our Line
The CLX-BPO2 brings industrial-grade stripping and trimming to our line, reducing cycle time while maintaining consistent prep.
Shanghai Weiye OFC Equipment uses the CLX-BPO2 to raise output and standardize prep quality. The unit cycles in ~1.5 seconds, yielding about 20 terminal preparations per minute in production.
PLC and photoelectric control enable precise detection and repeatable motion. That control keeps strip and stub lengths within tight tolerances.
Line Speed
Typical operation speed is ~1.5 seconds per cycle. This enables steady throughput under normal production conditions.
Supported Strip and Stub Lengths
The CLX-BPO2 handles LSZH/PVC with an adjustable jacket strip length from 17.5–35.0 mm. Reserved strength member stubs are adjustable from 7.0–11.0 mm to match common termination hardware.
Cutting FRP/Steel Members
The machine cleanly cuts FRP and steel wire strength elements while protecting neighboring fibers. Customized cutters are offered for nonstandard sizes to preserve precision.
- Auto-eject scrap and sensor start cut idle time.
- Compact size (L40 × W18 × H18 cm), 110–220V, 50W, and 11 kg weight ease integration into workcells.
- Cylinder-driven motion and PLC/photoelectric control boost reliability and lower maintenance interruptions.
| Spec | Rating | Why it matters |
|---|---|---|
| Cycle | ≈1.5 s (~20/min) | High throughput for production runs |
| Strip lengths (A) | 17.5 to 35.0 mm | Compatible with common connectors |
| Reserved stub (B) | 7.0–11.0 mm | Meets strength and termination needs |
| Power & size | 50W @ 110–220V; 40×18×18 cm | Simple integration |
Using this machine, Shanghai Weiye OFC Equipment standardizes prep so field teams get drop parts install-ready. The CLX-BPO2 helps our production lines meet volume goals without sacrificing quality.
Custom Specs for Your FTTH System
Shanghai Weiye OFC Equipment configures every order to meet your network requirements and simplify deployment. We pair concise options with predictable manufacturing windows so your teams get install-ready reels.
Choose 1–4 core designs with single-mode or multimode fiber. Options include OS1/OS2 plus OM2–OM4 along with G.652D and G.657 variants to align with optics and connector plans.
We Pantone-match sheath colors for fast field ID and consistent asset tagging.
Jackets, Legends & Branding
Select LSZH, PVC, or PE jackets to suit route and safety requirements. Custom print legends and logos aid inventory/warranty tracking.
Put-Ups, Packaging, and Structures
Standard put-ups are 1/2/4 km with custom reels and packaging to suit storage and handling. Choose bow-type flat or self-supporting designs and FRP or steel members to fit span and isolation requirements.
| Option | Typical | Advantage |
|---|---|---|
| Reel length | 1, 2, or 4 km | Simpler staging and reels |
| Jacket | LSZH, PE, PVC | Indoor/Outdoor fit |
| Design | Bow-type / Self-supporting | Routing and span flexibility |
As a supplier, Shanghai Weiye aligns runs to your schedule and provides docs that lists final specifications for straightforward QA on site.
QA, Testing & Documentation
Shanghai Weiye OFC Equipment builds checkpoints into production so every item ships with recorded acceptance data.
Lab Testing: Heat, Salt Spray & Vibration
Our lab conducts high-temperature exposure, salt fog corrosion, and vibration tests to qualify materials/assemblies. These tests recreate field stresses for indoor and outdoor use.
100% test reports for every cable
Every fiber optic cable ships with a 100% test report that logs attenuation, return loss, and geometry where applicable. Final QC gates prevent nonconforming shipments before they leave the factory.
Traceability & Compliance
Lot/batch records tie test data to reels and serials so audits and claims are easy to verify. Documentation follows common customer templates to accelerate approvals and receiving inspection.
- Line checks and final inspection reduce field failures and cut warranty events.
- Quality packages include specifications confirmation and formatted data for rapid review.
- Ongoing trend analysis drive preventive maintenance and improve long-term reliability.
| Test | Purpose | Result |
|---|---|---|
| High-temperature | Material stability | Pass at target temperature |
| Salt spray | Corrosion resistance | Qualified for outdoor use |
| Mechanical vibration | Mechanical robustness | Reduced field failures |
FTTH Drop Cable Pricing & Cost Drivers
Budget planning for a drop begins with fiber/jacket selection and is shaped by volume and customization.
Typical prices vary widely—from about $30–$1,000 per unit—based on fiber grade, jacket chemistry (LSZH, PVC, PE), length, and structural design.
Primary Cost Inputs
The primary cost drivers are fiber optic grade, jacket material, and the structural type chosen for deployment.
Self-supporting structures and steel strength elements increase material/labor. Custom colors, logos, and print legends add setup time and influence price for short runs.
Order length, volume, and customization impact on price
Longer put-ups and larger volumes reduce unit cost. Small quantities often include setup charges and higher per-unit charges.
- Changeovers and special cutters increase lead time and add cost.
- Clear RFQs and line scheduling let Shanghai Weiye OFC Equipment match quotes to delivery windows.
- Frameworks and indexed pricing stabilize budgets across phases.
| Factor | Effect on price | Guidance |
|---|---|---|
| Optical grade | High impact | Balance spec vs. budget |
| Sheath material | Medium | Compare LSZH vs. PE for total cost |
| Length/Volume | High impact | Consolidate runs to cut unit cost |
U.S. Lead Times, MOQ & Delivery
Shanghai Weiye OFC Equipment keeps lead times/logistics clear so planners can align crews and sites. Predictable windows reduce downtime and help control cost when a rollout is underway.
Production Windows & Capacity
Typical production windows run 4–5 days for orders under 100 km and 7–10 days for < 500 km. We schedule line capacity to track your milestones and to maintain on-time delivery.
The service team issues production updates and tracking so installation teams know when reels arrive. For tight schedules, we reserve contingency capacity to accelerate critical-path orders.
Why MOQ Matters
The MOQ is one kilometer. This reflects setup needs such as wire/die adjustments that use startup material and generate scrap.
We review your length and staging plans to select reels to reduce waste/handling. Staggered batches can balance inventory holding with frequent, smaller deliveries to job sites.
Where and How to Deploy
On-site conditions dictate whether a self-supporting aerial, ducted pull, or direct burial is the right choice for a project.
Aerial, duct, and direct-buried deployment considerations
For aerial runs, Shanghai Weiye OFC Equipment recommends self-supporting designs with appropriate members to manage sag/tension for long-term stability.
Duct installations perform best with low-friction sheaths and crush-resistant constructs so pulling does not damage fibers. PE jackets are typical for underground and buried paths where moisture resistance is needed.
Direct-buried designs require proper depth control per local codes and moisture-resistant jackets to protect the optic core over time.
Indoor Distribution and ONT
Indoor riser and plenum routes favor LSZH jackets to meet smoke/flame codes. Flat drop cable forms strip cleanly and present controlled stubs for fast ONT terminations.
We advise on steel vs FRP (dielectric) strength members based on bonding requirements, lightning risk, and hardware fit. Standardized line prep reduces install time and reduces scrap.
| Deployment | Key feature | Field note |
|---|---|---|
| Overhead | Self-supporting (steel/FRP) | Check tension and messenger hardware |
| Underground duct | Low-friction jacket, crush resistance | Use pull tape and proper lubricant |
| Direct burial | PE jacket, moisture barrier | Follow depth/warning tape codes |
| Indoor | LSZH jacket, tight bend support | Maintain bend radius at wall penetrations |
Our approach ensures a consistent install experience across indoor/outdoor transitions. That reduces callbacks, faster activations, and reliable field performance for your system.
Support from Spec to Service
Our team coordinates tests, line schedules, and installation guidance to avoid surprises in deployment.
Shanghai Weiye OFC Equipment offers engineering support from early requirements through approved drawings and pilot builds. We provide doc templates and clear installation notes so field crews share a unified plan.
After-sales service includes fast response, RCA, and corrective action. All products ship with full test reports and traceability to help QA acceptance.
- 24/7 availability for status updates and technical guidance.
- Warranty with free replacement if any quality problems are confirmed.
- Coordination of line schedules for urgent changes or acceleration requests.
- Config control so shipped items match agreed requirements every time.
| Area | Scope | Benefit |
|---|---|---|
| Tech/Eng | Spec review & pre-production builds | Reduced field issues |
| Testing | Lab + 100% reports | Full traceability |
| Service | Rapid replacement & root-cause | Lower downtime |
Final Thoughts
Select Shanghai Weiye OFC Equipment for custom drops, quick lead times, and full traceability.
We provide custom FTTH drops that combine materials with validated manufacturing and lab tests. Every reel includes a 100% test report and documented lab trials to support field acceptance in the United States.
A robust production line, including CLX-BPO2 prep assets, reduces variability and speeds turnaround. Our equipment set standardize strip/stub lengths so installers see consistent results at turn-up.
From fiber selection through jacket, printing, and packaging, we balance performance and cost to extend service life. Dedicated support covers scheduling/logistics/after-sales so your deployment remains on plan.
Get in touch with Shanghai Weiye OFC Equipment to align specifications, timeline, and volume. We stand behind every shipment with laboratory validation and responsive support.
